HP DesignJet T830 24inch Printer
This printer has been discontinued. Please shop for associated supplies.
Line drawings: 26 sec/page on A1/D, 81 A1/D prints per hour
Dye-based (C, M, Y); pigment-based (mK)
Media handling: Sheet feed, roll feed, input tray, media bin, automatic cutter
Gigabit Ethernet (1000Base-T); Wi-Fi 802.11b/g/n; Wi-Fi Direct
SKU :
HMOEPRHPT830Tags :
- HP ,
- HP Printer ,
- 24inch ,
- T830
Specifications
Functions | Print, copy, scan |
---|---|
Print speed | 26 sec/page on A1, 81 A1 prints per hour 1 |
Ink drop | 6 pl (C, M, Y); 12.6 pl (mK) |
Print head nozzles | 1376 |
Print cartridge volume delivered | HP 728 Ink Cartridge: matte black, cyan, magenta, yellow (300 ml); cyan, magenta, yellow (130 ml); matte black (69 ml); cyan, magenta, yellow (40 ml) |
Ink types | Dye-based (C, M, Y); pigment-based (mK) |
Number of print cartridges | 4 (C, M, Y, mK) |
Print heads | 1 (C, M, Y, mK) |
Color(s) of printing supplies | Cyan, magenta, yellow, matte black |
Print quality color (best) | Up to 2400 x 1200 optimised dpi |
Maximum optical density (black) | 8 L* min/2.10 D 2 |
Finished output handling | Sheet feed, roll feed, input tray, media bin, automatic horizontal cutter |
Media sizes standard (metric rolls) | 279 to 610 mm |
Roll external diameter | 100 mm |
Roll maximum input | 1 |
Roll maximum weight | 4.1 kg |
Media thickness | Up to 11.8 mil |
Media thickness (metric) | Up to 0.3 mm |
Media width, maximum | 610 mm |
Supported Primary Applications | Line drawings; Renderings; Presentations |
Non-printable area (cut-sheet) | 5 x 5 x 5 x 5 mm |
Non-printable area (roll media) | 5 x 5 x 5 x 5 mm |
Media sizes, custom | Input tray: 210 x 279 to 330 x 482 mm; Manual feed: 330 x 482 to 610 x 1897 mm |
Media sizes supported | Input tray: A4, A3; Manual feed: A2, A1 |
Media types | Bond and coated paper (bond, coated, heavyweight coated, recycled, plain, bright white), technical paper (natural tracing, vellum), film (clear, matte), photographic paper (satin, gloss, semigloss, premium, polypropylene), self-adhesive (adhesive, polypropylene) |
Media weight, recommended | 60 to 280 g/m² (roll/manual feed); 60 to 220 g/m² (input tray) |
Model size | 610 mm |
Internal Storage | None |
Line accuracy | ±0.1% 3 |
Printer drivers included | HP-GL/2, HP-RTL drivers for Windows; Raster driver for macOS and Windows |
Print languages | HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4, URF |
Print technology | HP Thermal Inkjet |
Theoretical minimum line width | 0.02 mm (HP-GL/2 addressable) |
Guaranteed minimum line width | 0.07 mm (ISO/IEC 13660:2001(E)) |
Printing path | Wi-Fi Direct to enable mobile printing via HP ePrint, Apple AirPrint and HP Smart app for Android and iOS devices, Windows and macOS printer drivers, printing support for Chrome OS, print from USB pen drive |
Average weekly print volume (D/A1) | 90 A1/D prints per week |
Copy reduce / enlarge settings | 50 to 400% |
Copier settings | Content type; Lighter/Darker; Background noise removal; Background colour removal; Blue print invert; Translucent media; Colour; Scan full width; Auto De-skew; Resize; Copy Margins; Quality |
Enhanced scanning resolution | 600 dpi |
Scan resolution, optical | Up to 600 dpi |
Linear scan speed | Up to 3.81 cm/sec (colour, 200 dpi); Up to 11.43 cm/sec (greyscale, 200 dpi) |
Scan file format | JPEG, PDF, TIFF |
Scan input modes | Scan to email, scan to cloud (through HP Smart app), network, USB, computer, mobile |
Maximum media thickness | 0.8 mm |
Scan size, maximum | 610 mm x 2.77 m |
Scan size, minimum | 203 x 127 mm |
Scanner type | Sheetfed, CIS (Contact Image Sensor), media jam detection sensor, front feed scanning method |
Connectivity, standard | Gigabit Ethernet (1000Base-T), Wi-Fi 802.11b/g/n |
Connectivity, optional | HP USB 3.0 to Gigabit LAN Adapter |
HP ePrint capability | Yes |
Network ready | Standard |
Mobile printing capability | Wi-Fi Direct and local Wi-Fi connectivity to enable mobile printing via HP ePrint, Apple AirPrint™ and HP Smart App. Supports printing from most smartphones and tablets using these operating systems: Android, iOS |
Minimum dimensions (W x D x H) | 1098 x 605 x 1155 mm |
Package dimensions (W x D x H) | 1310 x 570 x 645 mm |
Weight | 46.7 kg |
Package weight | 65.7 kg |
Memory | 1 GB |
Acoustic power emissions (active, printing) | 6.5 B(A) (operating), <3.4 B(A) (idle) |
Acoustic pressure emissions | 48 dB(A) (operating), <16 dB(A) (idle) |
Operating humidity range | 20 to 80% RH |
Non-Operating Humidity Range | 0 to 95% RH |
Operating temperature range | 5 to 40ºC |
Operating temperature range | 41 to 104ºF |
Storage temperature range | -25 to 55ºC |
Storage temperature range | -13 to 131ºF |
Power consumption | 35 watts (printing), 3.5 watts (sleep), 0.2 watts (standby) |
Power | Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 1.2 A max |
Software included | HP Click, HP Smart app, HP Support Assistant, HP Print Preview for Windows, HP DesignJet Utility for macOS and Windows |
Electromagnetic compatibility | Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC/R&TTE Directives), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI); Certified as Class A product: Korea (KCC) |
Energy star certified | Yes |
Environmental certification | ENERGY STAR, EPEAT, CE marking (including RoHS, WEEE, REACH). In compliance with WW RoHS materials restriction requirements in China, Korea, India, Vietnam, Turkey, Serbia, and Ukraine. |
Safety | USA and Canada (CSA certified); EU (LVD, EN 60950-1 and EN 62368-1 compliant); Russia (EAC); Singapore (PSB); China (CCC); Mexico (NYCE); Argentina (IRAM); India (BIS) |
Manufacturer Warranty | One-year limited warranty. Warranty and support options vary by product, country and local legal requirements. |
What's in the box | HP DesignJet T830 24-in MFP, printhead, ink cartridges, printer stand, spindle, quick reference guide, setup poster, startup software, power cord, refeed preventers |
Brand | hp |
