Panasonic PT-VMZ60 Laser LCD Projector
6,000 lm, WUXGA, portable LCD laser projector designed for education and corporate environments. This projector supports 4K and 30p signal input, making this projector a future-proofed solution to projecting the latest image quality and content.
- Laser LCD, 6,000 lumens, WUXGA
- Long lasting laser light source provides consistent brightness and 20,000 hours maintenance-free operation
- A 1.09:1 throw-ratio and a wide horizontal and vertical lens-shift allow to create large images even in small spaces
- Support 4K and 30p signal input, making the range a futureproofed solution to projecting the latest image quality and content.
- Optional Wireless projection capability
|Resolution||1920 x 1200 pixels|
|Light output*1||6,000 lumens|
|LCD panel | Panel size (mm)||16 mm diagonal (16:10 aspect ratio)|
|LCD panel | Panel size (inch)||0.64 inch diagonal (16:10 aspect ratio)|
|LCD panel | Display method||Transparent LCD panel (x 3, R/G/B)|
|LCD panel | Drive method||Active matrix|
|LCD panel | Pixels||2,304,000 (1920 x 1200) x 3, total of 6,912,000 pixels|
|LENS||1.6 x Manual zoom (throw ratio 1.09-1.77 :1), F = 1.60-2.12, f = 15.30-24.64 mm|
|Light source||Laser diode|
|Screen size (diagonal) (mm)||0.76 - 7.62 m, 16:10 aspect ratio|
|Screen size (diagonal) (inch)||30-300 in, 16:10 aspect ratio|
|Center-to-corner uniformity*1||85 %|
|Contrast*1||3,000,000:1 (all white/all black) (Input signals:PC,LIGHT POWER:NORMAL,PICTURE MODE:DYNAMIC,DAYLIGHT WIEW:OFF,DYNAMIC CONTRAST:1,AUTO POWER SAVE:OFF)|
|Optical axis shift | Vertical (from center of screen)||0 % - +44 % (Manual)|
|Optical axis shift | Horizontal (from center of screen)||- 20% - +20% (Manual)|
|Keystone correction range*2||Vertical: ±25°, Horizontal: ±35°|
|Installation||Horizontal/Vertical, free 360-degree installation|
|Terminals | HDMI 1/2 IN||HDMI 19-pin x 2 (Compatible with HDCP, Deep Color, 4K/30p signal input)|
|Terminals | COMPUTER 1 IN||D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR)|
|Terminals | COMPUTER 2 IN / MONITOR OUT||D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR) (input/output switching)|
|Terminals | VIDEO IN||Pin jack x 1|
|Terminals | AUDIO 1/2 IN||M3 stereo mini-jack x 2|
|Terminals | AUDIO 3 IN||Pin jack (L/R) x 1|
|Terminals | VARIABLE AUDIO OUT||M3 stereo mini-jack x 1|
|Terminals | SERIAL IN||D-sub 9-pin x 1 for computer control (RS-232C compliant)|
|Terminals | LAN||RJ-45 x 1 for network control, 10Base-T, 100Base-TX, compatible with PJLink™ (Class 2)|
|Terminals | DIGITAL LINK/LAN||RJ-45 x 1 for network and DIGITAL LINK connection, HDBase-T™ compliant, 100Base-TX, compatible with PJLink™ (Class 2), HDCP, Deep Color, 4K/30p signal input|
|Terminals | USB CONNECTOR||USB connector (Type A) x 1 for Memory Viewer function, power supply (DC5V, maximum 2A*3), optional wireless module AJ-WM50|
|Power supply||AC 100-240 V AC, 50/60 Hz|
|Built-in Speaker||10 W (monaural)|
|Operating noise*1||NORMAL: 37dB, QUIET: 27dB|
|Cabinet materials||Molded plastic|
Filter cleaning cycle: 20,000 hours (0.08 mg/m3 of particulate matter), 10,000 hours (0.15 mg/m3 of particulate matter)
|Dimensions (W x H x D) (mm)||399 x 115 x 348 mm (Not including protruding parts)399 x 133 x 348 mm (With feet at shortest position)|
|Dimensions (W x H x D) (inch)||15 23/32 x 4 17/32 x 13 11/16 inch (Not including protruding parts)15 23/32 x 5 1/4 x 13 11/16 inch (With feet at shortest position)|
|Weight (kg)*4||Less than 7.2 kg|
|Weight (lbs.)*4||Less than 15.87 lbs.|
|Operating environment (℃/M)||Operating temperature: 0 °C- 45 °C, operating humidity: 20 %-80 % (no condensation)|
|Operating environment (°F/Feet)||Operating temperature: 32 °F -113 °F, operating humidity: 20 %-80 % (no condensation)|
|Applicable software/application||Logo Transfer Software, Multi Monitoring & Control Software, Presenter Light for Windows®, Wireless Projector Apps for iOS/Android™|
|Note||*1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2012 international standards. Value is average of all products when shipped. |
*2 Around this time, light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast contents, NORMALMode, Dynamic Contrast , under conditions with 30 °C (86 °F), 700 m (2,297 ft) above sea level, and 0.15 mg/m3 of particulate matter. Estimated time until light output declines to 50 % varies depending on environment.
*3 On standby, power supply is available with Quick Startup set to ON or Power Management set to Ready.
*4 Average value. May differ depending on the actual unit.
|Color||White or Black|
